The HUADA CDb-21ZYN micro rectangular electrical connector is a powerful solution for modern electronic designs. With its 1.27mm pitch, it strikes the perfect balance between space efficiency and functionality. Whether you’re working on industrial automation, consumer electronics, or automotive applications, the CDb-21ZYN delivers. Its high-density design allows up to 51 cores, making it ideal for tight spaces where real estate matters. Plus, the robust construction ensures reliability even in extreme conditions, from frigid -55°C to scorching +125°C. When every millimeter counts, trust the CDb-21ZYN to connect your world.
Engineered to perfection, the CDb-21ZYN boasts precise features. The contact spacing of 1.27mm ensures secure connections, while the crimping cross-sectional area (ranging from 0.05mm² to 0.15mm²) guarantees efficient power transmission. It meets GJB2446 standards, and detailed specifications are available in Q/MB20604-2018 and Q/MB330A-2011. Whether you’re designing for military applications, aerospace, or telecommunications, the CDb-21ZYN stands tall. Experience the fusion of compact design, rugged performance, and compliance – all in one remarkable connector.
Key Features of the HUADA CDb-21ZYN Connector
High-Density Design: The CDb-21ZYN packs up to 51 cores into its compact form, making it ideal for space-constrained environments. Whether you’re designing for industrial automation, consumer electronics, or automotive applications, this connector delivers efficiency without compromising on performance.
Robust Construction: Operating from -55°C to +125°C, the CDb-21ZYN withstands extreme conditions. Its rugged build ensures reliability in harsh environments, providing peace of mind for critical applications.
Efficient Crimping: The contact spacing of 1.27mm ensures secure connections, while the crimping cross-sectional area (ranging from 0.05mm² to 0.15mm²) guarantees efficient power transmission.
Compliance and Standards: The CDb-21ZYN meets GJB2446 standards, with detailed specifications available in Q/MB20604-2018 and Q/MB330A-2011. It’s engineered for precision and reliability.
Technical Features Table:
| Minimum Operating Temperature |
-55 °C |
| Maximum Operating Temperature |
+125 °C |
| Current |
3 A |
| Insulation Resistance |
5000 mΩ |
| Mechanical life |
500 |
| Work pressure |
4.4 KPa |
| Pressure Resistant |
600 V |
| Contact Resistance |
8 mΩ |
| Vibration |
10~2000Hz 196m/S2 |
| Impact |
490 m/s2 |
| Relative humidity |
40℃, 98% |
|
|
High-Density Micro Rectangular Electrical Connector: HUADA CDb-21ZYN Images
|
